DTQ0.5-6 series of dynamic multi-energy extraction tank
Detailed description
The device is suitable for traditional Chinese medicine, food, chemical and other industries pigmentation atmospheric pressure, water extraction, alcohol extraction and extraction of aromatic oil extraction and recovery of organic solvents and other processes. Due to the use of intermediate mixing, forcing the medicine and the full contact with the solvent, greatly improving the extraction rate and the total dissolution of the active ingredient. The equipment has the advantages of high extraction efficiency, high yield of finished products, convenient operation and smooth operation. Equipment using low-carbon high-quality stainless steel, inner wall of fine polishing, no dead ends, is the pharmaceutical, food industry GMP transformation of the preferred equipment.
TECHNICAL DATA | ||||||
Project model | 0.5m3 | 1.0m3 | 2m3 | 3m3 | 6m3 | |
Total capacity L | 570 | 1200 | 2500 | 3500 | 6800 | |
Design pressure in tank | 0.09 | |||||
Design pressure in jacket | 0.3 | |||||
Permissible vacuum in tank | 60 | |||||
Air pressure in cylinders | 0.8 | |||||
Diameter of feeder nose mm | 300 | 300 | 400 | 400 | 500 | |
Heating area m2 | 2.4 | 3.1 | 4.2 | 5.5 | 7.1 | |
Condensing area | 3 | 5 | 5 | 5 | 8 | |
Cooling area m2 | 1 | 1 | 1 | 1 | 1 | |
Filtering area | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | |
Weight of equipment | 1000 | 1500 | 1800 | 2100 | 3500 | |
Motor power kw | 2.2 | 3 | 4 | 5.5 | 7.5 | |
Stirring rotation speed r / min | 85 | 85 | 85 | 85 | 85 | |
Dimensions | Φ1300 × 2130 | Φ1500 × 2650 | Φ1700 × 3180 | Φ1900 × 3800 | Φ2600 × 4500 | |
Main tank container category Vessel type first class | A class of ILE | |||||
Energy consumption | 200 | 245 | 325 | 425 | 580 | |
