JG100-50000 series fermentation tank
Detailed description
JG series fermentation tank is a kind of equipment for mechanical stirring and fermentation of materials. The equipment uses the internal circulation form, uses the stirring blade to disperse and break the bubble, its dissolving oxygen rate is high, the mixing effect is good, widely applies in the medicine, chemical industry, food and so on material ferment.
Item | 100L | 200L | 500L | 1m3 | 2m3 | 5m3 | 10m3 | 20m3 | 30m3 | 50m3 |
Fermenter diameter mm | 400 | 500 | 700 | 900 | 1200 | 1500 | 1700 | 2200 | 2600 | 3100 |
Fermenter height mm | 2000 | 2330 | 2650 | 2900 | 3800 | 4480 | 6415 | 7500 | 8415 | 10800 |
Tank pressure MPa | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
Jacketed pressure MPa | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.25 | 0.3 |
Stirring Number | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 4 |
Stirring speed V / min | 400 | 360 | 265 | 220 | 180 | 160 | 145 | 125 | 125 | 110 |
Motor power KW / H | 0.55 | 0.75 | 1.1 | 1.5 | 3 | 7.5 | 15 | 30 | 55 | 90 |
Cooling | Jacket | Tube | ||||||||
Container category | First class | |||||||||
